36″ Achelous AquaBox®

Description

Product DetailsTech SpecsProduct Resources

Product Details

AB36AB – Blue Thumb
36″ Achelous AquaBox^®

Blue Thumb’s patented AquaBox® basins are produced in-house. Our 36″ Achelous basin is designed to provide a plentiful water reservoir with strength enough to support expensive and heavy fountains on its manageable, lightweight form. This basin also features a 2-piece removable grate top that includes a cut out for easy pump access with a cover to keep debris out when not in use. Additional support columns may be added when using heavier fountains. Made in the USA.

Specifications:

• Round basin suitable for medium fountains
• Overall dimensions with lip 39.5” diameter X 16” high
• Full grate dimensions and basin inner seat 36″ dia. x 2.8″H
• 60 gallon capacity
• Maximum static load 1,000 lbs
• Weighs approximately 45 lbs

Basin Kit Includes:
    • Reservoir basin with 4 molded supports
    • 2-piece grate basin cover
    • PVC Center support column
    • Pump access cover

Recommended add-on products:
    • Auto Fill Valve paired with a 30 psi Regulator for automatic water level maintenance
    • Mesh Sediment Screen to reduce debris falling through grate into the basin
    • Splash Apron to help prevent water loss
    • 4-5 bags of Polished Pebbles, in black or mixed, will cover grate when finishing



Tech Specs

table,th,td{}td:nth-child(1){background-color: #f4f6fc;} “>

	36″ Achelous Basin – AB36AB	48″ Achelous Basin – AB48AB	52″ Altum Basin – AB52AB
Dimensions	Overall Round 39.5″ dia. x 16″H Full cover grate 36″ dia. x 2.8″H (2-halves with 2 pump access covers)	Overall Round 51..5″ dia. x 16″H Full cover grate 48″ dia. x 2.8″H (2-halves with 2 pump access covers)	Overall Square 52.5″ x 52.5″ x 20″H Full cover grate 48″ x 48″ x 2.8″ (2-halves with 1 pump access cover)
Gallon Capacity	60 Gallons	95 Gallons	220 Gallons
Maximum Static Load	750 lbs	1,500 lbs	2,500 lbs
Product Weight	Approx. 45 lbs	Approx. 64 lbs	Approx. 110 lbs
Fountain Size	For use with Medium Fountains	For use with Large Fountains	For use with Large or Multiple Fountains

Product Resources

36″ Achelous Basin
Spec Sheet

Achelous & Altum
Installation Manual

Auto Fill Installation Video

Testimonial
